The IDT-SBG100 P-Type Swing Gate is an advanced swing barrier gate engineered for modern access control environments that demand both security and style. With a precision DC brushless motor, durable SS304 stainless steel chassis, and elegant tempered glass wings, this Motorized P-Type Swing Gate ensures smooth, silent, and reliable passage control. The P-type design offers wider lanes for wheelchair and trolley access, making it a versatile solution for corporate, healthcare, and public facilities. Integrated infrared sensors enable anti-tailgating and safety detection, while intelligent logic controls allow single or bi-directional operation. The gate supports RFID, biometric, and face-recognition systems for a fully automatic swing gate experience.
Why Choose IDT P-Type Swing Gate?
Ready to enhance your premises with smart, secure access?
Transform your entryways with a P-Type Swing Barrier Gate crafted for performance, durability, and aesthetics.
The IDT-SBG100 Swing Barrier Turnstile is a premium P-Type Swing Gate designed to manage high pedestrian flow while maintaining smooth and silent movement. Built with SS304 stainless steel and tempered glass panels, it combines strength with aesthetic appeal. Its brushless DC motor guarantees over 8 million operating cycles with negligible maintenance.
This automatic swing gate offers adjustable single or bi-directional passage, supports fire-alarm signal input for emergency opening, and integrates easily with RFID, biometric, or face recognition terminals via TCP/IP or dry-contact I/O interfaces. Infrared sensors detect obstructions to prevent accidental closure and raise alerts on illegal intrusions. With a 600 mm passage width and 0.8-second opening speed, it provides efficient and accessible movement for all users. The gate’s intelligent control logic allows automatic reset within 5 seconds of inactivity, LED direction indicators (red × for no entry, green → for entry), and customizable access delay. Ideal for corporate offices, healthcare institutions, educational campuses, and retail environments, the IDT-SBG100 Swing Gate offers a perfect balance of safety, design, and performance.
| Technical Specification | |
|---|---|
| Dimension | 250(L) x 200(W) x 980(H) |
| Material | 304 original brushed stainless steel, acrylic |
| Channel Width | 562.5mm (900mm Can be Customized) |
| Full Thickness of The Outer Box | 0.8mm |
| Motor | 24V DC brushless motor, low noise |
| Movement Structure | 2-stage deceleration horizontal 3rd-generation movement |
| Main board | Brushless control system |
| Traffic Direction | One-way traffic/two-way traffic |
| Opening Signal | Dry contact signal |
| Life | ≥6 million times |
| Infrared Quantity | Single-shot infrared |
| Power | 40-70W |
| Applicable Temperature | -20~70 °C (add thermostat below this temperature) |
| Opening Mode | Card swiping and Face, Fingerprint verification opening, infrared induction automatic opening, button opening, etc. |
| Protection Function | Electromechanical anti-collision, infrared anti-pinch, wrong entry infrared alarm |
| Order Information | |
| Part No. | IDT.586100 |
