The IDT100100 AI-Based X-Ray Baggage Scanner is a premium, wide tunnel X-ray baggage inspection system engineered to handle oversized luggage, cargo, and high-volume passenger flows. Designed for airports, logistics hubs, stadiums, and other high-security venues, it combines advanced AI-assisted baggage X-ray scanning with a powerful single-energy X-ray system to automatically detect weapons, explosives, liquids, and contraband. Its expansive tunnel (1000 x 1000mm), high-speed conveyor, and high-resolution color display ensure rapid, accurate, and reliable inspection of suitcases, parcels, and freight.
Why Choose IDT100100 AI-Based X-Ray Baggage Scanner?
Ready to enhance your security operations with smart, automated screening?
Ensure precise, safe, and fast baggage screening with the IDT100100 AI-Based X-Ray Scanner.
The IDT100100 AI-Based X-Ray Baggage Scanner is a next-generation airport security baggage scanner designed for high-volume, high-security environments. Its expansive tunnel and high-speed conveyor allow efficient scanning of oversized luggage, parcels, and palletized cargo, ensuring smooth passenger and cargo flows. Integrated AI algorithms instantly analyze images, highlighting potentially dangerous or prohibited items to help operators make faster, more accurate decisions.
Built for durability, ease of use, and operational efficiency, the IDT100100 features a high-resolution color touchscreen, fingerprint login, sound and light alarms, baggage recording, and energy-saving functions. Its ability to handle bulkier items makes it ideal for airports, logistics hubs, stadiums, and other facilities where speed and accuracy are critical.
| Dimension | |
|---|---|
| Tunnel Dimension | 1000 mm (W) × 1000 mm (H) |
| System Dimension | 3276 mm (L) × 1296 mm (W) × 1810 mm (H) |
| General Specifications | |
| Conveyor Height | 300 mm |
| Conveyor Speed | 0.2 m/s, 0.3 m/s, 0.4m/s adjustable |
| Max. Conveyor Capacity | 200 kg |
| Performance | |
| Wire Resolution | 384/0 AWG |
| Penetration (Steel) | 34/36 mm |
| X-ray Generator | |
| Number of Generators | 1 |
| Anode Voltage / Current | 160KV |
| Cooling / Working cycle | Oil-cooling / Continuous |
| Health and Safety | |
| External dose rate | < 0.5 µSwh (50mm Distance to the Housing) |
| Film Safe | Guaranteed up to ISO1600 |
| Detection Algorithm | |
| Prohibited Goods | 35 Major Types, over 64 categories |
| Detection Others | Shield Alarms, etc. |
| Integrated Cameras | |
| Cameras | 5 camera, Resolution: 1920 x 1080 1/2.8″ |
| Sensor Type | Progressive Scan CMOS H.265 / H.264 / |
| Video Compression Standard | MJPEG |
| Installation Data | |
| Power Consumption | < 0.8 KVA |
| Power Supply | AC 220V (-15% to +10%), 50Hz/60Hz (±3Hz); AC 110V (-15% to +10%), 50Hz/60Hz (±3Hz); |
| Noise level | < 60 dB |
| Environment | |
| Operating Temperature / Humidity | 5°C to 40°C / 5 % to 95 % (non-condensing) |
| Storage Temperature / Humidity | -20°C to 60°C / 5 % to 95 % ( non-condensing) |
| Weight | 1000 Kg |
| Additional Features | |
| Image Processing | Color / Black & White(CR&W), Organic Stripping(ORG-), Inorganic Stripping(NIORG-), Negative, High / Low penetration (HI_), Absorptivity increase(ABS+), Absorptivity decrease(ABS-), Super Enhancement(SEN), Edge Enhancement (Edge), 64x seamless zoom in and out, etc. |
| Software Functions | Professional TIP system, Operation Intro, Photo and X-ray image connection, etc |
| Operation Display | 21.5 inch |
| Storage | 1,00,000 + |
| Order Information | |
| Part Number | IDT.100100AI |
